Main Features：
1.This equipment is in accordance with Current GMP Standard.
2.The drive parts and packing parts of this equipment are completely separate,it has simple construction,and easy to adjust,clean and maintain the machine.
3.It has high automation,automatically finish folding leaflet, opening box, cartoning bottles, printing batch number, sealing carton,besides its front and back can joint automatically with labelling machine.The whole machine has many automatic monitoring points,its running condition can show on touch screen at any time,it will stop working when it shows error.
4.It has high production efficiency.
5.It has advanced configuration,more than 90% electrical components adopts imported international famous brand,such as PLC adopt Siemens from Germany ,Breaker and Switching Button adopt Schneider from France,Photoelectric Element and Relay adopt Omron from Japan,Servo system adopts Mitsubishi from Japan etc.
6.It can design different mould according customer’s requirement.
|
Production Speed |
20-60boxes/min | ||
|
Box |
Quality Requirement |
350-400g/ m2(depend on box size) | |
|
Size(L×W×H) |
(80-160)×(40-80)×(40-60)mm | ||
|
Leaflet |
Quality Requirement |
55-70g/m2 | |
|
Unfolded size(L×W) |
(70-210)×(80-300)mm | ||
|
Folded size(L×W) |
(70-210)×(20-40)mm | ||
|
Compressed air |
Working Pressure |
0.5-0.7mpa | |
|
Air consumption |
7m3/h | ||
|
Power |
1.5kw | ||
|
Power Supply |
Three phase four wires 380V 50HZ | ||
|
Dimension(L×W×H) |
4100×800×1550mm | ||
|
Weight |
About 1t | ||
